4x4pro Video input
Your pro system is equipped with capture cards. These cards have the ability to capture live video from either SD-SDI or HD-SDI video sources with up to four unique feeds, or two unique 3G-SDI feeds per machine.
Max Number of Unique Inputs
| SD-SDI | HD-SDI | 3G-SDI |
|---|---|---|
| 4 | 4 | 2 |
Supported formats
720x486i @ 59.94 Hz NTSC 720x576i @ 50.00 Hz PAL 1280x720p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 59.94Hz, 60Hz 1920x1080i @ 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz 1920x1080PsF @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz 1920x1080p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz 2048X1080p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz 2048X1080i @ 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz 2048x1556PsF @ 14.98Hz, 15Hz, 18.98Hz, 19Hz 4K UHD 3840x2160, 4K P/PsF @ 23, 24, 25, 29, 30fps 4K DCI 4096x2160, 4K P/PsF, @23, 24, 25, 29, 30fps
It is possible to have a different format on each input, However the limitations are a maximum of 1x 4k or 2x 1080p60.
If you are using 1x 4k or 2x 1080p it is not possible to use any other video inputs on the unit due to hardware limitations.
Back-Plate Layout
Diagram of Video Capture BNC connections on rear of a unit.
4K resolutions is currently only supported over quad split HD-SDI
Supported formats
720x486i @ 59.94 Hz NTSC
720x576i @ 50.00 Hz PAL
1280x720p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 59.94Hz, 60Hz
1920x1080i @ 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz
1920x1080PsF @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz
1920x1080p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 47.96Hz, 48Hz, 50Hz,
59.94Hz, 60Hz
2048X1080p @ 23.976Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 47.96Hz, 48Hz, 50Hz,
59.94Hz, 60Hz
2048X1080i @ 47.96Hz, 48Hz, 50Hz, 59.94Hz, 60Hz
2048x1556PsF @ 14.98Hz, 15Hz, 18.98Hz, 19Hz
4K UHD 3840x2160, 4K P/PsF @ 23, 24, 25, 29, 30fps
4K DCI 4096x2160, 4K P/PsF, @23, 24, 25, 29, 30fps
It is possible to have a different format on each input, However the limitations are a maximum of 1x 4k or 2x 1080p60.
If you are using 1x 4k or 2x 1080p it is not possible to use any other video inputs on the unit due to hardware limitations.
Back-Plate Layout
Diagram of Video Capture BNC connections on rear of unit
