GX Range Overview
The Disguise GX range is designed to handle all the demands of playing back increasingly demanding generative video content at scale.
These are the current models in this range:
These are the legacy models in the range:
Technical specification comparison
Section titled “Technical specification comparison”Compare the technical specifications of the GX 3+ and GX 3 by referring to the table below:
| GX 3+ | GX 3 | |
|---|---|---|
| 4K Inputs | 3x 12G inputs or 12x 3G inputs (HD-BNC connectors) | 3x 12G inputs or 12x 3G inputs (HD-BNC connectors) |
| 4K Outputs | 3x 4K outputs using VFC cards (with integrated EDID management) | 3x 4K outputs using VFC cards (with integrated EDID management) |
| Network Ports | General Network: 4x 10GbE/sec (Ethernet) Media Network: Dual-port 100GbE (QSFP28) | General Network: 1x 1GbE/sec (Ethernet) 2x 10GbE Media Network: Dual-port 100GbE (QSFP28) |
| GPU | Nvidia RTX Pro 6000 Workstation Edition | NVIDIA RTX A6000 |
| CPU | AMD EPYC 4.1Ghz | Intel Xeon 3.1Ghz |
| Motherboard | PCIe 5.0 | PCIe 4.0 |
| Storage | 1x 3.84TB Removable NVMe SSD | 1x 3.84TB Removable NVMe SSD |
| Notchmarks | 143,699 | 53,045 |
| Video playback 4K DCI at 30fps | Notch LC - 14 layers HAP - 41 layers ProRes 422 - 14 layers< br> roRes 4444 - 7 layers | Notch LC - 9 layers HAP - 24 layers ProRes 422 - 7 layers ProRes 4444 - 3 layers |
