Card Configuration
The Disguise Solo comes in a variety of optional factory fitted configurations. Your machine configuration can only be changed by sending it back to Disguise to be upgraded. The following configurations are available:
- No capture, a choice of on-board audio or Pro Audio
- 10Gb Ethernet, a choice of on-board audio or Pro Audio
- HDMI capture, a choice of on-board audio or Pro Audio
- SDI capture, a choice of on-board or Pro Audio
Rear view card configuration
Slot A
Section titled “Slot A”Slot A is video output and is non-configurable. The Solo has 1 control / GUI output and 2 dedicated DisplayPort stage outputs.
Video output card
Section titled “Video output card”The solo has three DP 1.2 outputs (1x dedicated GUI, 2x Outputs)
The GUI output is located on the previously highlighted port. This port CANNOT be used to output to the stage.
Supported resolutions on the DisplayPort outputs are up to 4096x2160 @60hz.
Slot B
Section titled “Slot B”Slot B is by default blank, so the on-board audio is used but can be configured to be Pro Audio I/O when the order is placed.
Slot C
Section titled “Slot C”Slot C has four options - blank, HDMI capture, SDI capture or 10G Ethernet. Capture/Ethernet options are factory fitted.
HDMI Capture card
Section titled “HDMI Capture card”
Max resolution: 1x 4096x2160 @30 Hz or 2x 1920x1080p @60Hz
SDI Capture card
Section titled “SDI Capture card”
Max resolution 3x HD - SDI or 2x 3G - SDI
10G Ethernet card
Section titled “10G Ethernet card”
